• Whether the OASE modular filtration system is operated as a gravity-fed filter in the ground or as a pump-fed version. The ProfiClear M1 Classic pump chamber ensures the correct positioning of the filtration pump: • For reducing pressure losses • For safe set-up in swimming ponds in compliance with standards • For simple maintenance and over wintering • For protection against excessive sludge • Two inputs for connecting to the bottom drain and skimmer. • On the floor there is a sediment chamber for debris which leaves the pump chamber via the sludge drain. The ProfiClear M2 Classic coarse debris extractor enables simple and safe extraction of solids to a size of 300 microns. • Incoming water is fed via two large-surface extraction sieves into the next filter chamber. • By pulling the slide valve pollutants leave the system via a DN 50 pollutant discharge. This process is supported by rinsing nozzles. • The extraction sieves are easily cleaned when required. The surfaces can be cleaned in no time by interior and exterior brushes. Simply twist the cleaning handle to clean. • The pollutant level indicator signals the need for service. The ProfiClear M3 Classic filter foam module ensures safe removal of toxic substances like ammonium/ammonia or nitrite. • The water to be filtered is channelled through the coarse and fine foams where the filterbacteria that is so important has settled. • Connections on the housing enable simple entry of oxygen that is strictly required for the nitrification processes. • Cleaning is accomplished using the cleaning lever which compresses the foams between the intermediate floors. • Polluted water leaves the system through a DN 50 discharge that is opened with the slide valve. • The cleaning nozzle ensures that all the debris leaves the module. The ProfiClear M5 Classic phosphate binder module converts nitrate into gaseous nitrogen (denitrification) and eliminates phosphates. • A majority of the volume passes by the filter foam. In the process an oxygen-deficient area forms inside the foam, which is so important for the denitrification bacteria. • By-pass regulating in the foam prevents clogging so that this filter medium is maintenance free. • The lesser portion of the flow volume is channelled through Phosless inserts. • Binders ensure quick and safe phosphate removal. • Removal of these nutrients in particular visibly limits growth of string algae. • The pollutant level indicator signals the need for service.

• ProfiClear M1: Dimensions in mm (LxWxH) 800 x 600 x 800 InputsØ DN 100 / DN 150 Output 1 x 50 mm Hose connections for the outputs 1” – 2” Housing material quality Duroplast Guarantee 2 + 1 = 3 years ProfiClear M2: Dimensions in mm (LxWxH ) 800 x 600 x 800 Number of screens 2 Inputs Ø 1 x DN 100 / DN 150 + 2 x 50 mm Outputs Ø 1 x DN 100 / DN 150 Dirt outlet Ø DN 50 Flow max . in l / h 12500 Housing Material quality Duroplast Guarantee 2 + 1 = 3 years ProfiClear M3: Dimensions in mm (LxWxH) 800 x 600 x 800 Filter foam volume in l 70 Number of filter sponges 6 Inputs Ø 1 x DN 100 / DN 150 + 2 x 50 mm Outputs Ø 1 x DN 100 / DN 150 Dirt outlet Ø DN 50 Flow max . in l / h 12500 Housing Material quality Duroplast Guarantee 2 + 1 = 3 years ProfiClear M5: Dimensions in mm (LxWxH) 800 x 600 x 800 Number of filter columns / sponges 4/6 Inputs Ø 1 x DN 100 / DN 150 + 2 x 50 mm Outputs Ø 1 x DN 100 / DN 150 Dirt outlet Ø DN 50 Flow max . in l / h 12500 Housing Material quality Duroplast Guarantee 2 + 1 = 3 years
