• Product Details for FiltoClear 3000/6000 • Innovative, effective pressure filter range with integrated UVC-clarifier • Extremely user-friendly thanks to “Easy-Clean-Technology” • Sealed pressure container – thus the filters can be almost completely buried in the ground and can supply higher-elevation watercourses • Polluted water is pumped into a sealed, enclosed system, where a working pressure of 5 m head height can be built up Product details for FiltcoClear 12000/16000 • Combination of mechanical biological cleaning and effective UVC technology • Including OASE Clear Water Guarantee*C • Ideal for supplying higher elevated watercourses or waterfalls • Setup below the surface level of the water is also possible • Patented Easy-Clean-Technology for easy and convenient cleaning without opening the filter • Easy-to-operate waste outlet function • UVC indicator light for monitoring of the UVC clarifier • Pollutant level indicator and flow-through indicator • All function-regulating parts are arranged so that they are easily accessible in the cover • Through burying or covering with a decorative rock cover it can be perfectly integrated in the water garden • Perfectly suited for architectural pools thanks to virtually invisible technology • Optimal ratio of device dimensions and biological-mechanical cleaning capacity thanks to the compact design • High-quality, impact-resistant material • New: FiltoClear 12000 with improved UVC performance and filter performance compared to the predecessor model • Incl. UVC clear rinse function • Incl. 2″ hose connection Product details for FiltoClear 20000/30000 Clear water guaranteed through the ideal combination of filter, pump and UVC technology • Convenient cleaning thanks to patented Easy-Clean-Technology • The filter can be almost completely buried for almost invisible integration in the environment • Suitable for ponds up to 30,000 litres • Perfectly suited for architectural pools thanks to virtually invisible technology • Optimal ratio of device dimensions and biological-mechanical cleaning capacity thanks to the compact design • With 2″ hose connection • With UVC clear flush function

• FiltoClear 3000-: Suitable for ponds upto max. 7 m3 Suitable for ponds with fish max. 3 m3 Dimensions in mm (O x H) 380 x 430 Filter volume in litres 9 Inlets and outlets ¾” to 1 ½” Number of blue filter foams 3 Filter surface in m2 10.5 FiltoClear 6000: Integrated UVC Clarifier 9 W Suitable for ponds up to max. 4 m3 Suitable for ponds with fish max. 2 m3 Dimensions in mm (O x H ) 380 x 310 Filter volume in litres 5 Inlets and outlets ¾” to 1 ½” Number of blue filter foams 2 Filter surface in m2 5.3 FiltoClear 12000/16000: Rated voltage 220 – 240 V / 50 / 60 Hz Power cable length (m) 5.00 Guarantee*G (+ request guarantee) 2 + 1 years Pollutant level indicator Yes Connections, inlet 1 ½”, 2” Connections, outlet 1 ½”, 2” Connections, pollutant discharge 1 ½”, 2” Max. operating pressure 0.20 bar FiltoClear 20000/30000: Net weight (kg) 12 Length 393mm Width 393mm Height 810mm Rated Voltage 230 V / 50Hz Power cable length 5m Guarantee (+ request guarantee) 2 + 1 years Number of blue filter foams 6 unit Number of red filter foams 7 unit Pollutant level indicator Yes Connections, inlet 1 ½”, 2” Connections, outlet 1 ½”, 2” Connections, sludge discharge 1 ½”, 2” Pump capacity, max. 16,000 l/h Max. operating pressure 0.2 bar
• FiltoClear 12000/16000/20000/30000 Operating Instructions
