• Product characteristics • Suitable for ponds up to 18 m³ (BioSmart 18000) and 36 m³ for (BioSmart 36000) • Additional oxygen enrichment through special water channelling • Cleaning handles for convenient maintenance • Including displays for pollutant level and water temperature • Sludge drain for easy removal of coarse debris • Easy to conceal; the filter can be recessed into the ground to ? of its height • Optimally matched to the OASE AquaMax filter and watercourse pumps

• BioSmart 18000:- Dimensions (L x W x H) (mm) 382 x 555 x 408 Rated Voltage – Power consumption – Power cable length (m) – Net weight (kg) 5.80 Guarantee 3 years UVC Power – Number of filter foams, total (EA) 4 Number of blue filter foams (EA) 2 Number of red filter foams (EA) 1 Number of green filter foams (EA) 1 Temperature display Yes Connections, inlet (mm) 25/32/38 Connections, inlet 1” 1 ¼”, 1 ½” Connections, outlet DN 75 Connections, sludge discharge DN 50 Max. flow rate l/h 5500 Suitable for ponds up to max. (m³) 18.0 BioSmart 36000:- Dimensions (L x W x H) (mm) 767 x 555 x 408 Rated Voltage – Power consumption – Power cable length (m) – Net weight (kg) 10.70 Guarantee 3 years UVC Power – Number of filter foams, total (EA) 9 Number of blue filter foams (EA) 4 Number of red filter foams (EA) 4 Number of green filter foams (EA) 1 Temperature display Yes Connections, inlet (mm) 25/32/38 Connections, inlet 1” 1 ¼”, 1 ½” Connections, outlet DN 75 Connections, sludge discharge DN 50 Max. flow rate l/h 8000 Suitable for ponds up to max. (m³) 36.0
• BioSmart 18000 and 36000 Operating Instructions
