Description

• Description
• Specifications
• Downloads

• General Description

  Product characteristics • Extremely quiet operation • Easy adjustment of the flow rate • Integrated thermal protection – from 600 onwards • Can be used underwater or dry installations • Energy-efficient thanks to low energy consumption • Frost-resistant to –20 °C • High-quality workmanship with stainless steel • Priming even at low water levels (to 12000) • Removable pedestal for installation where space is at a premium (to 12000)

• Aquarius Universal 21000 (item no. 56870):- Dimensions (L x W x H) (mm) 420 x 220 x 262 Rated voltage 220 – 240 V / 50 Hz Power consumption 470 W Power cable length (m) 10.00 Net weight (kg) 14.18 Guarantee*G (+ request guarantee) 3 + 2 Years Max. flow rate (l/min) 363 Max. flow rate (l/h) 21800 Max. head height (m) 9.60 Connection, pressure-side 2” Connection, suction-side 2” Connection for hoses 1”, 1 ½”, 2” Filter intake surface (cm²) 1350 Electronic adjustment Yes Setup type Can be setup underwater and dry Aquarius Universal 27000 (item no. 56871):- Dimensions (L x W x H) (mm) 420 x 220 x 262 Rated voltage 220 – 240 V / 50 Hz Power consumption 645 W Power cable length (m) 10.00 Net weight (kg) 14.12 Guarantee*G (+ request guarantee) 3 + 2 Years Max. flow rate (l/min) 450 Max. flow rate (l/h) 27000 Max. head height (m) 10.00 Connection, pressure-side 2” Connection, suction-side 2” Connection for hoses 1”, 1 ½”, 2” Filter intake surface (cm²) 1350 Electronic adjustment Yes Setup type Can be setup underwater and dry Aquarius Universal 40000 (item no. 56872):- Dimensions (L x W x H) (mm) 461 x 234 x 293 Rated voltage 220 – 240 V / 50 Hz Power consumption 1000 W Power cable length (m) 10.00 Net weight (kg) 19.68 Guarantee*G (+ request guarantee) 3 + 2 Years Max. flow rate (l/min) 667 Max. flow rate (l/h) 40000 Max. head height (m) 11.00 Connection, pressure-side 2” Connection, suction-side 2” Connection for hoses 1”, 1 ½”, 2” Filter intake surface (cm²) 1650 Electronic adjustment Yes Setup type Can be setup underwater and dry
• Aquarius Universal 21000/27000/40000 operating instructions brochure
