Description
-
Description
Submersible centrifugal pump with ADJUSTMENT
RING impeller impeller suitable for lifting water from
drainage waste containing solids having maximum size
of 5 mm. Aluminium top cover with built-in handle.
Impeller in reinforced nylon with corrosion-proof
fiberglass. Pump and motor body in anodized die
cast aluminium. Carbon/alumina mechanical seal.
Dry type asynchronous sealed motor. Rotor mounted
on ball bearings to ensure silent running and long
life. Built-in capacitor in the single-phase version.
Thermal and overcurrent protection is the responsibility
of the user. Constructed in compliance with CEI 2-3CEI
61-69 (EN 60335-2-41) standards. -
Features
Motor protection level: IP 68
Insulation class: F
Continuous duty with completely immersed pump. The
single-phase version can be equipped with float switch
for automatic starting and stopping of the pump.
Supplied as standard with 10 metre H07RN-F power
cable.
Operating range: from 3 to 24 m3/h with head up to
14 mt.
Liquid quality requirements: Clear drain not
aggressive water
Liquid temperature range: from 0° to 35° for
domestic use
Maximum immersion depth: 10 mt
Installation: portable, in vertical position.
Free passage through the suction grid : 5 mm
